Seller Type Municipal/Government Fleet
**To Be Sold Pending Seller Confirmation**
Hours 3,422
Title Brand No Title - Bill of Sale
Title Status No Title
Drive Status Starts/Runs
**As-Is/Where-Is: No Guarantee On Roadworthiness Or Drive Status**
Fuel Diesel
Transmission Automatic
Color Yellow
VIN/SERIAL T0310SG961233

Manufacturer's Specifications:

ENGINE / POWER
Engine: John Deere 4045T, 4-cylinder, turbocharged diesel

Displacement: 4.5 L (276 cu in)

Gross/Net power: ~ 91 hp (≈ 67.9 kW) @ 2,000 rpm

Peak torque: ~ 276 lb-ft (≈ 374 Nm) @ 1,400 rpm

Fuel type: Diesel

Fuel tank capacity: ~ 36 US gallons (≈ 136 L)

TRANSMISSION / DRIVE / CHASSIS
Drive: 2WD (4×2) or 4WD (MFWD)

Transmission: 4-speed, full power shift (4 forward / 4 reverse)

Max travel speed (forward & reverse): ~ 20.5 mph (≈ 33 km/h)

Steering: Hydrostatic power steering

Brakes: Hydraulic wet disc

WEIGHT, DIMENSIONS & UNDERCARRIAGE
Operating weight (standard 2WD): ~ 13,500 lb (≈ 6,120 kg)

Max operating/working weight (with heavier config): up to ~ 15,955 lb (≈ 7,237 kg)

Transport dimensions:

Length: ~ 23.5 ft (≈ 7,160 mm)

Width: ~ 7.16 ft (≈ 2,180 mm)

Height (to top of cab / ROPS): ~ 9.17 ft (≈ 2,790 mm)

Wheelbase: ~ 6.89 ft (≈ 2,100 mm)

Ground clearance: ~ 13 in (≈ 330 mm)

HYDRAULICS
Hydraulic system type: gear-pump, open-center

Pump flow capacity: ~ 28 gal/min (≈ 106 L/min)

Relief (system) pressure: ~ 3,625 psi

Fluid capacities:

Hydraulic system fluid: ~ 24 gal (≈ 91 L)

Engine oil: ~ 13 L

Coolant: ~ 16 L

LOADER (FRONT)
Bucket capacity: ~ 1.3 yd³ (~ 1.0 m³)

Bucket width: ~ 92 in (~ 2,340–2,390 mm)

Lift capacity at full height: ~ 7,340 lb (~ 3,330 kg)

Bucket breakout / breakout force: ~ 10,210 lb (~ 4,630 kg)

Dump-height clearance: ~ 11.2 ft (≈ 3,400 mm)

BACKHOE (REAR)
Standard digging depth: ~ 14.5 ft (≈ 4,420 mm)

Extended digging depth (with extend-a-hoe / extended-stick): ~ 18.4 ft (≈ 5,610 mm)

Standard reach from swivel: ~ 18.3 ft (≈ 5,560 mm)

Extended reach from swivel: ~ 21.9 ft (≈ 6,680 mm)

Standard bucket digging force: ~ 11,990 lb (~ 5,440 kg)

Extended-stick digging force (when extended): ~ 12,158 lb (~ 5,515 kg)

Standard load-height (for loading): ~ 11.25 ft (≈ 3,430 mm)

Extended load-height: ~ 14.1 ft (≈ 4,290 mm)

Maximum reach at load height (standard / extended): ~ 21.75 ft / ~ 25.3 ft

**Disclaimer: The manufacturer's specifications provided are for reference only, and we disclaim any liability for inaccuracies or discrepancies. Specifications may vary by model or trim, and stock photos are used for illustrative purposes only and may not accurately represent the actual product. Please refer to the actual product for precise details.**
